РусскийParameter:
| Rated current | 16A/32A/63A/125A |
| Poles | 3P/4P/5P |
| Voltage | 200V-250V/380V-415V |
| Clock position | 6h |
| Hertz | 50-60Hz |
| Protection type | IP44/IP67 |
Panel-Mount Sockets are industrial-grade receptacles designed for permanent power access and high-reliability connectivity, securely installed on equipment panels, distribution enclosures, or control cabinets. Their primary function is to provide a safe and stable power interface for industrial machinery, electrical systems, or mechanical equipment, while meeting stringent requirements for ingress protection (e.g., IP44/IP67), electrical specifications (voltage/current ratings), and mechanical durability.
| Rated current | 16A/32A/63A/125A |
| Poles | 3P/4P/5P |
| Voltage | 200V-250V/380V-415V |
| Clock position | 6h |
| Hertz | 50-60Hz |
| Protection type | IP44/IP67 |
High Safety Performance
Water & Dust Resistance: IP67 or higher ingress protection ensures reliable operation in extreme environments, including heavy rain, dust, and oil contamination.
Shock Prevention: Recessed pin design and mechanical interlock mechanisms (requiring power disconnection before mating) minimize operational risks.
Flame Retardancy: PA6 housing provides high-temperature resistance (-40°C to 125°C) and meets flame-retardant standards.
Durability & Reliability
Extended Mating Cycles: Nickel-plated high-quality copper alloy contacts support over 10,000 insertion/extraction cycles.
Mechanical Impact Resistance: Rugged construction withstands drops, compression, and frequent vibrations, making it ideal for demanding industrial applications (e.g., construction machinery).
Flexible Adaptability
Modular Design: Compatible with various cable configurations (e.g., 5-core cables for three-phase power + grounding + signal transmission).
Color Coding: Voltage differentiation via color-coded rings (e.g., yellow for 110V, blue for 230V) prevents mismating errors.
Maintenance-Friendly & Long Service Life
Detachable Structure: The socket module and panel base feature a separable design, allowing internal component replacement without disassembling the entire unit, significantly reducing maintenance costs.
Aging Resistance: UV-stabilized housing material withstands prolonged ultraviolet exposure (e.g., outdoor photovoltaic power stations), with a lifespan exceeding 100,000 mating cycles.
Structural design
Pin layout: Asymmetric design (such as 3P+E) is adopted to ensure the only insertion direction.
Sealing structure: Rubber sealing ring + thread locking to achieve double waterproofing.
Application Scenario
Heavy industry: port cranes, welding equipment, automated production lines.
Outdoor scenes: stage lighting, temporary power supply stations, new energy charging piles
