РусскийParameter:
| Rated current | 16A/32A/63A/125A |
| Poles | 3P/4P/5P |
| Voltage | 200V-250V/380V-415V |
| Clock position | 6h |
| Hertz | 50-60Hz |
| Protection type | IP44/IP67 |
Industrial connectors are high-performance electrical interface devices specifically engineered for complex industrial environments, facilitating power transmission, signal control, and data communication between equipment, machinery, and control systems. Distinguished from commercial-grade plugs and sockets, their defining characteristics lie in structural robustness, operational reliability, environmental resilience, and modular configurability, enabling reliable operation under harsh industrial stressors such as vibratory stresses, particulate infiltration, moisture exposure, elevated temperatures, and corrosive agents.
| Rated current | 16A/32A/63A/125A |
| Poles | 3P/4P/5P |
| Voltage | 200V-250V/380V-415V |
| Clock position | 6h |
| Hertz | 50-60Hz |
| Protection type | IP44/IP67 |
Extreme Environmental Adaptability
Ingress Protection Rating: IP44/IP67 certified for dust and water resistance.
Shock & Vibration Resistance: Mechanical latching mechanism ensures secure mating under intense vibratory conditions.
Material Durability: Engineered thermoplastic housing provides UV resistance, oil contamination tolerance, and thermal stability across a wide temperature range (-40°C to +120°C).
High Load Capacity & Safety Performance
Electrical Specifications: Supports current ratings from 16A to 125A and voltages up to 1000V (compliant with IEC 60309 standards).
Safety Certifications: Internationally recognized certifications including CE, TUV, and RoHS compliance, with full adherence to EMC (Electromagnetic Compatibility) requirements for electromagnetic interference immunity.
Structural design
Pin layout: Asymmetric design (such as 3P+E) is adopted to ensure the only insertion direction.
Sealing structure: Rubber sealing ring + thread locking to achieve double waterproofing.
Application Scenario
Heavy industry: port cranes, welding equipment, automated production lines.
Outdoor scenes: stage lighting, temporary power supply stations, new energy charging piles
